W12-75
Soundsation
HYPER BASS 15A
Stok Kodu :
1200 Watt Birch15" Bass reflex active subwoofer
| Bass-reflex Active Subwoofer | |
| 15" woofer | |
| 1200 Watt class D amplifier | |
| Integrated active crossover | |
| XLR L/R Balanced Line Inputs | |
| XLR L/R Balanced Filtered Outputs, XLR L/R Balanced Link Outputs | |
| Controls | Sub Level, 80-120Hz crossover switch, 0-180° Phase, Shape switch, Ground Lift On-Off |
| RMS, Overload, Thermal limiter protection | |
| Multiplex Birch plywood enclosure with painted black finish | |
| 2 lateral recessed handles | |
| M20 type speaker pole mount to reduce vibrations | |
| Predisposition for 4 wheels (not included) | |
| Dimensions (LxHxW) | 520 x 670 x 625 mm |
| Weight | 29 Kg |
| Bass reflex active subwoofer | |
| Woofer | 15”, 4” voice coil |
| Amplifier | 1200W Peak/ 600W RMS, Class-D |
| Max SPL(Peak) | 124dB |
| Crossover Frequency | 120 Hz (24dB/Oct.) |
| Frequency Response [- 10dB] | From 35 Hz to 150 Hz |
| Frequency Response [- 3dB] | From 40 Hz to 120 Hz |
| LEDs | Power On (Green), Signal (Green) / Limit (Red) |
| Power Requirement | 230Vac - 50 Hz |
| Minimum Power Consumption | 750W |
| Power Connector | VDE with T5AL-250V Fuse |
| Dimensions (LxHxW) | 520 x 670 x 625 mm |
| Weight | 29 Kg |
- BEE23564.pdf İndir
