MC9160-7
| Bass-reflex Active Subwoofer | |
| 18" woofer | |
| 1200 Watt class D amplifier | |
| Integrated active crossover | |
| XLR L/R Balanced Line Inputs | |
| XLR L/R Balanced Filtered Outputs, XLR L/R Balanced Link Outputs | |
| Controls | Sub Level, 80-120Hz crossover switch, 0-180° Phase, Shape switch, Ground Lift On-Off |
| RMS, Overload, Thermal limiter protection | |
| Multiplex Birch plywood enclosure with painted black finish | |
| 2 lateral recessed handles each side | |
| M20 type speaker pole mount to reduce vibrations | |
| Predisposition for 4 wheels (not included) | |
| Dimensions (LxHxW) | 620 x 700 x 740 mm |
| Weight | 37 Kg |
Bass reflex active subwoofer
Woofer 18”, 4” voice coil
Amplifier 1200W Peak/ 600W RMS, Class-D
Max SPL(Peak) 126dB
Crossover Frequency 120 Hz (24dB/Oct.)
Frequency Response [- 10dB] From 30 Hz to 150 Hz
Frequency Response [- 3dB] From 35 Hz to 120 Hz
LEDs Power On (Green), Signal (Green) / Limit (Red)
Power Requirement 230Vac - 50 Hz
Minimum Power Consumption 750W
Power Connector VDE with T5AL-250V Fuse
Dimensions (LxHxW) 620 x 700x 740 mm
Weight 37 Kg
