Soundsation
HYPER PRO 12 ACX
Stok Kodu :
12” Polypropylene1600W Peak 2-way Powered Loudspeakers with DSP
Bi-Amped Active Speaker | |
1600W Peak Power | |
Amplifier | Class-D (low-frequencies); Class-AB (high-frequencies) |
Celestion® 1.4" Compression Driver | |
4-Preset DSP (Live, DJ, Speech, Monitor) | |
Balanced MIC / Line XLR input with Thru XLR output, Line Stereo input with 2x ¼ "jack, Stereo input with Mini-Jack and RCA, all with independent level controls | |
Link output with Mono / Stereo selection | |
Blue Front LED with On/Off Switch | |
Sturdy Polypropylene Enclosure with black anti-scratch paint | |
Flyable | 3 x M10 (2 on Top, 1 on Rear) |
Handles | 1 on top, 2 on sides |
Dual pole mount | Standard 36 mm, 0° and 7° |
Frequency Response | 50Hz - 20kHz / -10dB |
Max SPL | 134 dB |
Low-freq. Transducer | 12" Woofer |
High-freq. Transducer | Celestion® 1.4" Compression Driver |
Coverage | 90° x 90° |
Low-Frequency Amplifier | Class-D 350W RMS - 1400W Picco |
High-Frequency Amplifier | Class-AB 50W RMS - 200W Picco |
AC Mains | 100-120VAC/220-240VAC |
Power Consumption (Average/Peak) | 800W / 1600W |
Fuse | T6.3AL 250V (100-120V) / T3.15AL250V (220-240V) |
DSP | 4 preset (Live, DJ, Speech, Monitor) |
Input Connections | 1x XLR connector, 2x 63mm Jack, 1x Mini-Jack, 1x RCA Pair |
Output Connectors | 1x XLR Thru Output (Input 1), 1x XLR Link Output with Mono/Stereo selection |
Housing Material | Polypropylene |
Grille | Steel/1.2mm |
Flyable | 3 x M10 points (2 on top, 1 on rear) |
Handles | 2 on sides; 1 on top |
Dual tripod/pole hole | Standard D36mm, 0° and 7° |
Speaker Size (WxHxD) | 362 x 597 x 347 mm |
Packing Size (WxHxD) | 405 x 645 x 395 mm |
Speaker Weight | 15.5 kg |
Carton Weight | 17 kg |
