HYPER PRO 15 ACX
Stok Kodu :
15” 1800W polypropylene Peak 2-way Powered Loudspeakers with DSP
| Bi-Amped Active Speaker | |
| 1800W Peak Power | |
| Amplifier | Class-D (low-frequencies); Class-AB (high-frequencies) |
| Celestion® 1.4" Compression Driver | |
| 4-Preset DSP (Live, DJ, Speech, Monitor) | |
| Balanced MIC / Line XLR input with Thru XLR output, Line Stereo input with 2x ¼ "jack, Stereo input with Mini-Jack and RCA, all with independent level controls | |
| Link output with Mono / Stereo selection | |
| Blue Front LED with On/Off Switch | |
| Sturdy Polypropylene Enclosure with black anti-scratch paint | |
| Flyable | 3 x M10 points (2 on top, 1 on rear) |
| Handles | 1 on top, 2 on sides |
| Dual pole mount | D36mm Standard, 0° and 7° |
| Frequency Response | 45Hz - 20kHz / -10dB |
| Max SPL | 136 dB |
| Low-freq. Transducer | 15" Woofer |
| High-freq. Transducer | Celestion® 1.35" Compression Driver |
| Coverage | 90° x 90° |
| Low-Frequency Amplifier | Class-D 400W RMS - 1600W Picco |
| High-Frequency Amplifier | Class-AB 50W RMS - 200W Picco |
| AC Mains | 100-120VAC/220-240VAC |
| Power Consumption (Average/Peak) | 900W / 1800W |
| Fuse | T6.3AL 250V (100-120V) / T3.15AL250V (220-240V) |
| DSP | 4 preset (Live, DJ, Speech, Monitor) |
| Input Connections | 1x XLR connector, 2x ¼" Jack, 1x ?" Mini-Jack, 1x RCA Pair |
| Output Connectors | 1x XLR Thru Output (Input 1), 1x XLR Link Output with Mono/Stereo selection |
| Housing Material | Polypropylene |
| Grille | Steel/1.2mm |
| Flyable | 3 x M10 points (2 on top, 1 on rear) |
| Handles | 2 on sides; 1 on top |
| Dual tripod/pole Hole | D36mm Standard, 0° and 7° |
| Speaker Size (WxDxA) | 445 x 376 x 698 mm |
| Packing Size (WxDxH) | 490 x 425 x 745 mm |
| Speaker Weight | 20.5 kg |
| Carton Weight | 23.0 kg |
