SH153E
Soundsation
SCENIC 100W WW-CW
Stok Kodu :
1x100W COB Warm White + Cool White LED Fresnel Studio Projector with barn door
| High brightness / long lifespan LED (2260lux @2meter, full color) | |
| Warm and Cold white mixing (2 independent LED chips) | |
| Fresnel Lens and adjustable barn-doors for up to 60° angle | |
| Fan speed controlled by temperature | |
| Advanced dimmer system | |
| Extremely lightweight (only 1.5kg) |
| Light source | 100W COB LED |
| Color | 50W WW + 50W PW |
| Optical System | 60° Lens with adjustable barn-doors |
| Lux@ 1m | 10500 (full color); 5700 (cool white); 5000 (warm white) |
| Lux@ 1m | 7570 (full color); 3900 (cool white); 3680 (warm white) |
| Lux@ 2m | 2680 (full color); 1400 (cool white); 1300 (warm white) |
| Lux@ 2m | 2260 (full color); 1210 (cool white); 1100 (warm white) |
| Control mode | DMX512 5CH/2CH |
| Master/slave modes | Yes |
| Manual Control | Yes |
| Fan | Threshold 58~60°C (it stops when LED board temperature reduce to 40°C) |
| Fan Noise | 0dB (under 58°C); 44.0 dBA @ 0.5m (above 58°C); 46.1 dBA close to fixture. |
| IP Rate | IP20 |
| Working Temperature | –20°C ~ 40°C |
| Housing | ABS |
| Voltage | 110V ~ 240V, 50-60Hz |
| Power Consumption | 100W |
| Fixture Size (LxHxD) | 150 x 195 x 220 mm |
| Fixture Weight | 1.5 kg |
| Master Carton Size | 520 x 500 x 260 mm (8pcs) |
| Master Carton Weight | 15.5 kg (8pcs) |
